Outside dimension

8450×4000×3400 mm（L×W×H）

Front door

Folding door, 3   folds, 3000×2600 mm（W×H）,   without frame, colour : blue.

Emergency door

1 unit,   650×1800mm （W×H）, colour: blue, on the front door.

Basement

Galvanized   steel assemble, 300mm high, quadrate steel support, full grilles made by flat   bar and twisted steel, then galvanized. 2 ramps, external setting, 750×3000mm/pc.

Wall Board

Thickness:50mm,   width:1150mm, tongue and groove structure, 0.376mm colour steel   with 50mm thick polystyrene (EPS) insulation inside, colour: white.

Light

Ceiling   Lights: 8Units×4Pcs=32Pcs×36W, with   electronic ballasts, lighting boxes open outside,.

Side   Lights: 8Units×4Pcs=32Pcs×36W, with electronic   ballasts, lighting boxes pen outside

Generator cabinet

Intake   from rear upper direction, exhaust from rear upper direction, quadrates steel   frame; white coated steel covered, filled with heat preservation material in   the middle.

Intake and   Exhaust   system

2×3KW double-intake centrifugal fans   for intake, motor outside, belt drive, model TAE-355, air   capacity for each fan: 21000m3/h.

1×4KW double-intake centrifugal fan for   exhaust, motor outside, belt drive, model TAE-400, air capacity: 12500m3/h.

Heating system

RIELLO   G20 diesel burner, stainless steel heat exchanger, electric damper actuates   from spraying to baking cycle. Max. heating productivity: 20000kcal/h. Max   temperature: 80 degree

Purification   system

Pre-filter,   ceiling filter, fibreglass filter, activated carbon filter

Roof

Galvanized   steel plates

Control system

Spraying,   heat spraying, baking, time setting, lighting switch, failure indicator,   thermostat, power supply switch, emergency stop, hour meter. Temperature limit controller, all   motors are normal start.

Total Power

12.5KW
